Outdoor X-Leg Garden Bench

A crossed-leg outdoor bench I designed to practise flat-pack detailing — welded steel frame with bolt-on timber slats.

Type
Personal practice project
Location
Kampala, Uganda
Year
2026
Turnaround
4 days
Before / After

From rough idea to production-ready

Before — initial concept sketch for Outdoor X-Leg Garden Bench, Product Design project by DesignForge UgandaBefore
Pencil sketch of the X-leg bench concept on sketchbook paper.
After — finished CAD design of Outdoor X-Leg Garden Bench, Product Design project by DesignForge UgandaAfter
Production model — frame welds first, slats bolt on for flat-pack shipping.
The Challenge

What needed to be designed

I used this piece to practise designing for shipping — separating welded sub-assemblies from bolt-on parts and writing a simple assembly guide.

The Approach

How DesignForge approached it

  1. 1

    Designed the crossed-leg frame as a welded sub-assembly that ships flat.

  2. 2

    Standardised 7 timber slats (3 back, 4 seat) bolted with hidden M8 fasteners.

  3. 3

    Produced shop drawings plus a one-page assembly guide.

The Deliverable

What was produced

Production model — frame welds first, slats bolt on for flat-pack shipping.

Tools

Software and capabilities used

  • SolidWorks 3D Modeling
  • Fabrication Drawing
Skills Demonstrated

What this project put into practice

Design-for-flat-pack

Skill practised

M8 concealed

Hidden fasteners

7 standardised

Slat count

Shop drawings + guide

Deliverable
